ABB YPK107E

Description

Product Description

The ABB YPK107E is a robust operator interface pushbutton station designed for industrial control panels and machinery. This product combines a durable illuminated pushbutton with an integrated legend plate, providing a clear visual and tactile interface for operators to initiate commands, acknowledge statuses, or trigger specific machine functions. The ABB YPK107E is part of ABB’s comprehensive range of control and signaling devices, engineered for reliable operation in demanding industrial environments. For detailed technical specifications, dimension drawings, and mounting instructions, the essential resource is the official ABB Electrification Products catalog for the ABB YPK107E. Implementing the YPK107E pushbutton contributes to a safe, intuitive, and professional operator panel layout. Its design emphasizes durability, clear indication, and ease of installation, making it a fundamental component for human-machine interaction across various automation applications.

Product Parameters

• Manufacturer / Brand: ABB.
• Series: YPK Series (Illuminated Pushbuttons / Signaling Devices).
• Model: YPK107E (specific variant indicating color, voltage, and contact configuration).
• Function: Illuminated Pushbutton with Legend.
• Contact Configuration: Typically features a single-pole, changeover contact block (SPDT – 1NO+1NC). The “E” suffix may indicate a specific voltage rating or contact material.
• Voltage/Current Rating: Rated for low-voltage control circuits, commonly up to 600V AC/DC with a specific current rating (e.g., 6A or 10A).
• Illumination: Equipped with an integral lamp (incandescent or LED, depending on variant) available in various colors (e.g., red, green, yellow, white).
• Lens/Legend: Features a square or rectangular lens with a clear, customizable legend area for text or symbols to indicate its function (e.g., START, STOP, RESET).
• Actuation Type: Momentary or maintained (latching) operation, depending on the specific order code and internal mechanism.
• Mounting: Designed for mounting in a standard 22.5mm or 30mm cut-out in a panel door or enclosure.
• Protection Rating: Typically offers a front panel protection rating of IP65 (dust-tight and protected against water jets) when properly installed with its sealing gasket.
• Termination: Screw terminals for secure wiring connections.

Advantages and Features

• High Durability and Long Life: Built with robust materials to withstand millions of mechanical operations and resist impacts, chemicals, and UV exposure common in industrial settings.
• Clear Visual Indication: The illuminated lens provides unmistakable status feedback, even in brightly lit or dark environments, enhancing operator safety and awareness.
• Professional Appearance: The uniform design and customizable legend plates contribute to a clean, organized, and user-friendly control panel interface.
• Easy Installation and Maintenance: The modular design allows for easy mounting, wiring, and replacement of the lamp or entire unit if necessary.
• Versatile Application: Available in multiple colors, voltage ratings, and contact configurations, the ABB YPK107E can be specified for a wide range of control and signaling functions.

Application Cases in Industry

• Machine Control Panel: The ABB YPK107E (green) serves as the illuminated START button on a packaging machine control station, with a red YPK107E acting as the STOP/E-STOP button.
• Process Skid Operator Station: Used as an illuminated ACKNOWLEDGE or RESET button on a chemical dosing skid control panel to silence an alarm and reset a fault condition.
• Conveyor System Control Box: Functions as a local JOG or RUN pushbutton for maintenance personnel to manually control a section of conveyor.
• HVAC Control Panel: Installed as a MANUAL/AUTO selector switch (using a maintained action variant) on an air handling unit controller.
• Pump Control Cabinet: Serves as a illuminated REMOTE/LOCAL mode selector pushbutton for a pump control system.

Comparison with Competing Products

Competing products are illuminated pushbuttons from other major electrical component manufacturers, such as Siemens (3SB1 series), Schneider Electric (Harmony XB4/XB5), and Eaton (M22-D). The ABB YPK107E differentiates itself through its strong brand recognition in automation and its integration within ABB’s broader panel component ecosystem. Compared to a generic or low-cost pushbutton, the YPK107E offers proven mechanical life, better sealing (IP65), and consistent quality. Its primary advantage is for engineers and panel builders who standardize on ABB components, ensuring a consistent look, reliable supply chain, and compatibility with other ABB devices in the cabinet.

Selection Suggestions and Precautions

• Selection Suggestions:
  1. Select the ABB YPK107E based on the required function: choose the correct lens color (per standards: green for start, red for stop/emergency, yellow for intervention, etc.), contact configuration (NO, NC, changeover), and voltage rating for your control circuit.
  2. Decide between momentary (spring-return) or maintained (push-on/push-off) action based on the operational logic.
  3. Order the appropriate legend plate with the correct text or symbol to clearly identify the button’s purpose.
• Precautions:
  1. Correct Lamp Voltage: Ensure the supply voltage for the lamp matches the YPK107E‘s specified lamp voltage (e.g., 24V DC, 120V AC). Using an incorrect voltage will burn out the lamp immediately.
  2. Contact Rating: Do not exceed the electrical rating of the contact block. This pushbutton is for control circuit signals, not for switching high-power motor loads directly. Use a contactor or relay for higher loads.
  3. Proper Sealing: To achieve the stated IP65 rating, ensure the sealing gasket is correctly installed between the button and the panel, and that the mounting nut is tightened to the specified torque.
  4. Wiring and Strain Relief: Use the correct wire gauge and ensure wires are securely terminated. Implement proper strain relief for the cables entering the panel to prevent stress on the pushbutton terminals.
  5. Sourcing and Accessories: Source from authorized ABB distributors. Remember to order any separate contact blocks, legend plates, or lamps if they are not included in the base assembly. Follow the installation manual for proper assembly sequence.
