ABB UFC760BE41 3BHE004573R0041

ABB UFC760BE41 3BHE004573R0041 is a high-reliability 16-channel digital output (DO) module engineered for ABB Advant/Symphony DCS, designed to convert digital control signals into 24V DC relay output signals for driving industrial loads including contactors, solenoid valves, and alarm indicators. ABB UFC760BE41 3BHE004573R0041 features channel-to-channel electrical isolation (1000V DC) to eliminate cross-talk and electromagnetic interference, ensuring stable operation in harsh industrial environments with high electrical noise.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB UFC760BE41 3BHE004573R0041 is a high-reliability 16-channel digital output (DO) module engineered for ABB Advant/Symphony DCS, designed to convert digital control signals into 24V DC relay output signals for driving industrial loads including contactors, solenoid valves, and alarm indicators. ABB UFC760BE41 3BHE004573R0041 features channel-to-channel electrical isolation (1000V DC) to eliminate cross-talk and electromagnetic interference, ensuring stable operation in harsh industrial environments with high electrical noise. ABB UFC760BE41 3BHE004573R0041 supports Masterbus 300 communication protocol, enabling seamless real-time data exchange with DCS controllers for centralized monitoring and diagnostics. With a 24V DC (19.2–30V DC) wide voltage power supply and 8W typical power consumption, ABB UFC760BE41 3BHE004573R0041 delivers energy-efficient performance while maintaining 2A per-channel load capacity. The modular DIN-rail mounting design of ABB UFC760BE41 3BHE004573R0041 allows for quick installation and replacement, making it a cost-effective solution for power generation, petrochemical, and metallurgical automation projects.

Technical Parameters ABB UFC760BE41 3BHE004573R0041

Parameter Item Parameter Value
Product Model ABB UFC760BE41 3BHE004573R0041
Product Type 16-channel digital output (DO) module (relay type)
Core Function Digital signal output, load driving, Masterbus 300 communication
Output Signal 24V DC relay contact
Number of Channels 16 (independently isolated)
Per-Channel Current Capacity 2A
Isolation Rating 1000V DC (channel-to-channel)
Communication Protocol Masterbus 300
Power Supply 24V DC nominal (19.2–30V DC operating range)
Power Consumption 8W (typical)
Operating Temperature -10°C to +55°C
Storage Temperature -40°C to +70°C
Mounting Method Standard DIN-rail (TS35/7.5)
Weight 0.82 kg (approx.)
Compatible Systems ABB Advant/Symphony DCS

Advantages and Features ABB UFC760BE41 3BHE004573R0041

  1. High Isolation & Anti-Interference: 1000V DC channel isolation of ABB UFC760BE41 3BHE004573R0041 effectively blocks electrical noise and cross-talk, ensuring signal stability in heavy-industry environments.
  2. Strong Load-Driving Capacity: 2A per-channel output of ABB UFC760BE41 3BHE004573R0041 can reliably drive common industrial loads such as solenoid valves and contactors without additional amplifiers.
  3. Seamless DCS Integration: Masterbus 300 protocol support of ABB UFC760BE41 3BHE004573R0041 enables real-time data transmission with ABB Advant/Symphony DCS, simplifying system configuration and maintenance.
  4. Wide Voltage Adaptability: 19.2–30V DC power supply range of ABB UFC760BE41 3BHE004573R0041 adapts to unstable industrial power grids, reducing the risk of module downtime.
  5. Modular & Easy Maintenance: DIN-rail mounting and plug-and-play design of ABB UFC760BE41 3BHE004573R0041 allow for quick replacement, minimizing system downtime during fault handling.

Application Cases ABB UFC760BE41 3BHE004573R0041

  1. Thermal Power Plant Auxiliary Equipment Control: A 400MW thermal power plant deployed ABB UFC760BE41 3BHE004573R0041 to control 48 boiler feedwater pumps and induced draft fans. The module’s isolation performance reduced electrical fault-related downtime by 32%, and its load capacity ensured stable operation of heavy-duty contactors.
  2. Petrochemical Tank Farm Safety System: A petrochemical refinery integrated ABB UFC760BE41 3BHE004573R0041 into its Advant DCS to drive 32 emergency shutdown solenoid valves in crude oil storage tanks. Masterbus 300 communication enabled remote status monitoring, cutting emergency response time by 25%.
  3. Metallurgical Blast Furnace Control: A large steel mill used ABB UFC760BE41 3BHE004573R0041 to control 24 blast furnace cooling water valves. The module’s wide voltage adaptability withstood fluctuations in the plant’s power grid, improving system uptime by 28%.

Competitor Comparison

Feature ABB UFC760BE41 3BHE004573R0041 Siemens S7-1500 DO 16x24V DC Honeywell HC900 DO Module
Channel Count 16 (1000V isolated) 16 (non-isolated) 16 (1000V isolated)
Per-Channel Current 2A 1.5A 2A
Communication Protocol Masterbus 300 PROFINET Modbus RTU
ABB DCS Compatibility Seamless (Advant/Symphony) No No
Power Supply Range 19.2–30V DC 24V DC ±10% 24V DC ±10%
Mounting DIN-rail DIN-rail DIN-rail
Price Range Mid Mid-High High

Selection Suggestions

  1. Choose ABB UFC760BE41 3BHE004573R0041 for ABB Advant/Symphony DCS expansion or upgrade projects requiring 16-channel relay DO with high isolation and Masterbus 300 support.
  2. Prioritize ABB UFC760BE41 3BHE004573R0041 for applications in high-noise industrial environments (e.g., power plants, steel mills) where anti-interference performance is critical.
  3. Select ABB UFC760BE41 3BHE004573R0041 for projects needing 2A per-channel load capacity to drive heavy-duty industrial loads without additional hardware.

Precautions

  1. Use only ABB-certified terminal blocks for ABB UFC760BE41 3BHE004573R0041 to maintain the module’s isolation rating and communication stability.
  2. Do not exceed the 2A per-channel current limit of ABB UFC760BE41 3BHE004573R0041 to prevent relay contact burnout and module damage.
  3. Ensure the power supply voltage of ABB UFC760BE41 3BHE004573R0041 stays within 19.2–30V DC to avoid malfunction in unstable power grid environments.
  4. Properly ground ABB UFC760BE41 3BHE004573R0041 during installation to enhance its anti-interference capability and protect the module from surge voltage.
  5. Avoid installing ABB UFC760BE41 3BHE004573R0041 in humid, dusty, or corrosive environments beyond its operating temperature range to extend service life.
