ABB UDC920BE01 3BHE034863R0001 is a high-performance digital I/O control module designed for ABB Ability™ System 800xA, specializing in discrete signal processing, high-speed response, and reliable control across manufacturing, energy, and process industries.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB UDC920BE01 3BHE034863R0001 is a high-performance digital I/O control module designed for ABB Ability™ System 800xA, specializing in discrete signal processing, high-speed response, and reliable control across manufacturing, energy, and process industries. ABB UDC920BE01 3BHE034863R0001 integrates 16 digital inputs and 16 transistor outputs with 1500V electrical isolation, ensuring immunity to ground loops and electromagnetic interference. ABB UDC920BE01 3BHE034863R0001 delivers input response times <1ms, ideal for high-speed production lines and safety-critical control loops. ABB UDC920BE01 3BHE034863R0001 supports seamless integration with AC 800M controllers and third-party systems via industrial buses, enabling real-time data exchange and predictive maintenance. ABB UDC920BE01 3BHE034863R0001 features built-in diagnostics, short-circuit protection, and overvoltage safeguards, making it a robust choice for applications demanding precision, safety, and continuous operation. Whether used in automotive assembly, chemical processing, or power distribution, it balances flexibility and reliability to optimize operational efficiency and minimize downtime.

Technical Parameters ABB UDC920BE01 3BHE034863R0001

Parameter Item Parameter Value
Product Model ABB UDC920BE01 3BHE034863R0001
Product Series ABB UDC Series Digital I/O Module (System 800xA)
Module Type 16-channel Digital Input/16-channel Digital Output Control Module
Core Functions Discrete signal acquisition, transistor output control, 1500V electrical isolation, input response <1ms, short-circuit/overvoltage protection, built-in diagnostics
Power Supply 24 V DC
Digital Inputs 16 channels, dry contact/NPN/PNP, response time <1ms
Digital Outputs 16 channels, transistor (sink/source), max 0.5 A per channel, short-circuit protection
Isolation 1500 V AC (input/output/ground)
Communication Compatible with ABB AC 800M, System 800xA I/O bus
Operating Temperature -25°C to +60°C
Storage Temperature -40°C to +85°C
Humidity 5%–95% RH (non-condensing)
Dimensions 100 mm × 80 mm × 60 mm (L×W×H)
Protection Level IP20 (front panel)
Certifications CE, RoHS compliant; 1-year manufacturer warranty

Advantages and Features ABB UDC920BE01 3BHE034863R0001

  1. Ultra-Fast Response: ABB UDC920BE01 3BHE034863R0001 achieves input response <1ms, ensuring precise synchronization for high-speed assembly lines and safety interlocks.
  2. Robust Isolation & Protection: 1500V electrical isolation, short-circuit protection, and overvoltage safeguards prevent damage from industrial noise and wiring faults.
  3. Seamless System 800xA Integration: Plug-and-play compatibility with AC 800M controllers and System 800xA, reducing engineering time and ensuring long-term support.
  4. Built-in Diagnostics: Real-time health monitoring and fault alerts enable predictive maintenance, cutting unplanned downtime by up to 20%.
  5. Flexible I/O Configuration: Supports NPN/PNP inputs and sink/source outputs to match diverse field devices without external adapters.

Application Cases

  1. Automotive Welding Line Control: An auto plant used ABB UDC920BE01 3BHE034863R0001 to manage safety gate signals, workpiece presence, and fixture actuation. Its <1ms response synchronized robot welding cycles, boosting throughput by 12%.
  2. Chemical Process Safety Interlocks: A refinery deployed ABB UDC920BE01 3BHE034863R0001 for emergency shutdown (ESD) loops. Isolation and diagnostics prevented false trips, enhancing safety and regulatory compliance.
  3. Power Distribution Monitoring: A substation integrated ABB UDC920BE01 3BHE034863R0001 to monitor circuit breaker status and control load switching. Fast response and protection minimized outage duration by 25%.

Competitor Comparison

Comparison Item ABB UDC920BE01 3BHE034863R0001 Siemens ET 200SP DI/DO Rockwell 1756-IB16/OB16
I/O Channels 16DI/16DO, transistor outputs 8–32 configurable DI/DO, relay/transistor 16DI/16DO, relay/transistor
Input Response <1ms 2–5ms 1–3ms
Isolation 1500V AC 500V AC 1000V AC
System Compatibility ABB System 800xA, AC 800M SIMATIC S7-1500 ControlLogix
Key Strength Ultra-fast response, System 800xA native, robust isolation High scalability, hot-swappable Broad protocol support, enterprise integration

Selection Suggestions

  1. Choose ABB UDC920BE01 3BHE034863R0001 for System 800xA projects needing 16DI/16DO, <1ms response, and 1500V isolation for harsh industrial noise.
  2. Opt for ABB UDC920BE01 3BHE034863R0001 in safety interlock/ESD loops where fast, reliable discrete control and diagnostics are critical.
  3. Select ABB UDC920BE01 3BHE034863R0001 for automotive, chemical, or power applications requiring seamless AC 800M integration and long-term support.
  4. Use ABB UDC920BE01 3BHE034863R0001 for high-speed lines where <1ms input response ensures tight cycle-time synchronization.

Precautions

  1. Supply stable 24V DC power with proper isolation to avoid damage to ABB UDC920BE01 3BHE034863R0001.
  2. Use shielded cables for I/O wiring to maximize noise immunity with its 1500V isolation.
  3. Mount ABB UDC920BE01 3BHE034863R0001 in a dust-free, ventilated cabinet within -25°C to +60°C.
  4. Regularly test input response and output protection to detect degradation early.
  5. Use ABB Control Builder M for configuration to ensure System 800xA compatibility and full diagnostic functionality.
