ABB TC625

Description

Product Description

The ABB TC625 is a high-performance temperature transmitter from ABB’s renowned field instrumentation portfolio. This device is a two-wire, loop-powered temperature transmitter designed to interface directly with temperature sensors such as RTDs (Resistance Temperature Detectors) and Thermocouples (TCs). The TC625 Transmitter converts the low-level signal from the temperature sensor into a standardized and robust 4-20 mA analog output signal, which is immune to electrical noise over long cable runs. The ABB TC625 is engineered for reliable and accurate temperature measurement in demanding industrial process environments.

Product Parameters and Specifications

• Product Type: Two-Wire Temperature Transmitter.
• Sensor Input: Compatible with a wide range of sensors:
  • RTDs: Pt100, Pt500, Pt1000 (in various wiring configurations: 2-, 3-, or 4-wire).
  • Thermocouples: Types J, K, T, E, N, R, S, B, C.
• Output Signal: 4-20 mA DC, two-wire, loop-powered (the power for the transmitter is derived from the same two wires that carry the output signal).
• Power Supply: Typically operates from a 12-35 VDC loop supply.
• Accuracy: High accuracy, typically within ±0.1% of span or better, depending on sensor type and configuration.
• Display: Optional local LCD display for on-site reading of temperature, percent output, and diagnostic messages.
• Communications: Most models support HART protocol digital communication superimposed on the 4-20 mA signal, allowing for remote configuration, calibration, and diagnostics using a HART communicator or host system.
• Ambient Temperature Range: Designed for wide operating temperatures, suitable for installation in harsh field environments.
• Enclosure: Robust housing with high ingress protection (e.g., IP66, IP67, NEMA 4X).

Advantages and Features

1. Exceptional Accuracy and Stability: The ABB TC625 utilizes advanced digital signal processing and sensor-specific linearization algorithms to provide precise and drift-free temperature measurement, which is critical for process control and quality assurance.
2. Simplified Installation and Reduced Wiring Costs: As a two-wire, loop-powered device, it requires only two wires for both power and signal. This drastically simplifies installation compared to four-wire transmitters or direct sensor wiring to a distant I/O card, saving significant material and labor costs.
3. Robust HART Communication for Smart Capabilities: HART protocol support turns the TC625 into a smart field device. It enables remote configuration, troubleshooting, and retrieval of detailed diagnostics (e.g., sensor health, process variable) without needing to access the device physically.
4. Unmatched Sensor Flexibility: A single TC625 transmitter model can be configured for a vast array of RTD and thermocouple types, reducing spare parts inventory and providing great flexibility for plant engineers.
5. Rugged and Reliable Field Design: Built to withstand extreme environmental conditions including moisture, dust, vibration, and corrosive atmospheres, ensuring long-term reliability with minimal maintenance.

Application Cases in Various Fields

• Chemical and Petrochemical Processing: Measures critical temperatures in reactors, distillation columns, heat exchangers, and storage tanks for precise process control and safety monitoring.
• Oil & Gas Production: Used on pipelines, wellheads, and separators to monitor process fluid temperatures for flow assurance, safety, and custody transfer calculations.
• Power Generation: Monitors steam, feedwater, and bearing temperatures in turbines, boilers, and generators to ensure efficient and safe operation.
• Pharmaceutical and Food & Beverage: Provides accurate temperature measurement for batch reactors, fermentation tanks, pasteurizers, and sterilizers where strict temperature control is mandated.

Comparison with Competing Products

• vs. Direct Sensor Connection to PLC/DCS I/O Card: Connecting sensors directly brings low-voltage signals over long distances, making them highly susceptible to noise and requiring expensive shielded cables. The TC625 transmitter conditions the signal at the source and transmits a robust 4-20 mA signal, offering superior noise immunity and accuracy.
• vs. Four-Wire Transmitters: Four-wire transmitters require separate power and signal wires. The two-wire ABB TC625 simplifies design, reduces wiring costs, and is the industry standard for most field temperature measurements.
• vs. Other Brand Temperature Transmitters (e.g., Emerson Rosemount 3144, Siemens Sitrans TH): Competing transmitters offer similar core functionality. The TC625 is distinguished by ABB’s specific sensor algorithms, its proven reliability, seamless integration with ABB systems, and its intuitive configuration via HART.

Selection Suggestions and Precautions

1. Correct Sensor Type and Wiring Configuration: The most critical step is to correctly configure the TC625 for the specific sensor type (e.g., Pt100 3-wire) and measurement range. An incorrect setting will yield completely erroneous readings.
2. Loop Power Supply and Load Considerations: Ensure the DC power supply can provide sufficient voltage (considering wire resistance) to power the transmitter (minimum ~12V) and drive the 4-20 mA signal through the total loop resistance (including the input impedance of the receiving PLC/DCS card).
3. Proper Sensor Installation: The transmitter’s accuracy depends on a correctly installed sensor. Ensure good thermal contact, use appropriate thermowells for process insertion, and follow best practices for sensor mounting.
4. Utilize HART Diagnostics: Configure the control system or use a handheld communicator to routinely check the transmitter’s diagnostic status. This can provide early warning of sensor degradation or wiring issues before they cause a process problem.
5. Intrinsic Safety (IS) Requirements: For use in hazardous areas, the TC625 must be paired with an approved intrinsic safety barrier or isolator. Ensure the chosen model has the necessary safety certifications (e.g., ATEX, IECEx) for your application area.
