ABB SC510 3BSE003832R1

ABB SC510 3BSE003832R1 is a 4-channel asynchronous serial communication module, specifically designed for ABB AC 800M controllers and compatible with 800xA and Symphony®Plus DCS.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB SC510 3BSE003832R1 is a 4-channel asynchronous serial communication module, specifically designed for ABB AC 800M controllers and compatible with 800xA and Symphony®Plus DCS. ABB SC510 3BSE003832R1 acts as a key bridge connecting legacy serial devices and modern control systems, enabling data exchange between sensors, intelligent meters, and PLCs via configurable RS-232C/RS-485 interfaces. ABB SC510 3BSE003832R1 supports Modbus RTU/ASCII protocols, with flexible configuration of baud rate, data bits, and check bits to adapt to diverse device requirements. ABB SC510 3BSE003832R1 features channel-specific electrical isolation and IP20 protection, ensuring stable operation in harsh industrial environments with electromagnetic interference. ABB SC510 3BSE003832R1 adopts DIN rail mounting and integrates with AC 800M backplane bus, simplifying installation and system expansion.

Technical Parameters ABB SC510 3BSE003832R1

Parameter Item Parameter Value
Product Model ABB SC510 3BSE003832R1
Product Type 4-channel asynchronous serial communication module
Applicable System ABB AC 800M controller, 800xA DCS, Symphony®Plus DCS
Core Function Serial data exchange, legacy device integration, multi-protocol conversion
Communication Channels 4 independent configurable channels
Interface Standard Each channel configurable as RS-232C or RS-485
Communication Protocols Modbus RTU (Master/Slave), ASCII
Operating Mode Full-duplex (RS-232C), half-duplex (RS-485)
Baud Rate 300 bps – 115.2 kbps (configurable)
Data/Stop/Check Bits Data bits: 7/8; Stop bits: 1/2; Check bits: None/Even/Odd
Isolation Performance Electrical isolation between channels and backplane
Communication Distance Up to 1200m (RS-485)
Power Supply Powered by AC 800M backplane bus
Operating Temperature -25°C to +70°C
Storage Temperature -40°C to +85°C
Protection Level IP20
Mounting Type DIN rail mounting (AC 800M rack compatible)
Dimensions Approximately 120mm × 45mm × 115mm
Weight ~0.4 kg
Certifications CE
MTBF ≥ 600,000 hours
Warranty 1 year

Advantages and Features ABB SC510 3BSE003832R1

  1. Dual-Interface Flexibility: Configurable RS-232C/RS-485 channels of ABB SC510 3BSE003832R1 adapt to short/long-distance and point-to-multipoint communication scenarios.
  2. Strong Anti-Interference: Electrical isolation design of ABB SC510 3BSE003832R1 blocks ground loop interference, ensuring 99.9% communication stability in harsh industrial environments.
  3. Broad Protocol Support: Modbus RTU/ASCII compatibility of ABB SC510 3BSE003832R1 enables integration with most serial industrial devices.
  4. Seamless System Integration: Perfect matching with AC 800M and 800xA systems of ABB SC510 3BSE003832R1 avoids compatibility issues and reduces integration complexity.
  5. Easy Configuration: Flexible parameter adjustment of ABB SC510 3BSE003832R1 via Control Builder M software simplifies on-site debugging.
  6. Space-Saving Design: Compact size and DIN rail mounting of ABB SC510 3BSE003832R1 optimize cabinet space utilization.

Application Cases ABB SC510 3BSE003832R1

  1. Chemical Plant Instrument Integration: A refinery used ABB SC510 3BSE003832R1 with AC 800M controllers to connect RS-485-based flow/pressure meters, realizing centralized data collection and reducing wiring costs by 30%.
  2. Food Beverage Production Line Control: A bottling plant deployed ABB SC510 3BSE003832R1 to link legacy weighing systems (RS-232C) with 800xA DCS, ensuring precise material dosing and production traceability.
  3. Power Substation Legacy Device Upgrade: A utility integrated ABB SC510 3BSE003832R1 to connect old RTU devices with Symphony®Plus DCS, avoiding costly device replacement and ensuring smooth data transmission.
  4. Automotive Parts Testing Equipment: A manufacturing facility used ABB SC510 3BSE003832R1 to exchange data between test benches (RS-485) and AC 800M controllers, enabling real-time monitoring of test parameters and improving test efficiency.

Competitor Comparison

Feature ABB SC510 3BSE003832R1 ABB CI854A (Ethernet/Serial Gateway) Siemens CP 341 (Serial Communication Module)
Communication Channels 4 (configurable RS-232C/RS-485) 2 (fixed RS-485) 1 (configurable RS-232C/RS-422/RS-485)
Protocol Support Modbus RTU, ASCII Modbus RTU, PROFIBUS Modbus RTU, ASCII, 3964(R)
Compatibility AC 800M/800xA/Symphony®Plus AC 800M S7-300 Series
Isolation Performance Channel/backplane isolation Basic isolation Channel isolation
Communication Distance Up to 1200m Up to 1000m Up to 1200m
Price Range Mid-Range Mid-High Range Mid-Range

Selection Suggestions

  1. Choose ABB SC510 3BSE003832R1 for AC 800M/800xA/Symphony®Plus systems needing multi-channel serial communication and legacy device integration.
  2. Prioritize ABB SC510 3BSE003832R1 for scenarios requiring both RS-232C and RS-485 interfaces (e.g., mixing short/long-distance devices).
  3. Select ABB SC510 3BSE003832R1 for harsh industrial environments with electromagnetic interference, relying on its isolation design for stable communication.

Precautions

  1. Confirm compatibility with AC 800M controller models before installing ABB SC510 3BSE003832R1.
  2. Correctly configure interface type (RS-232C/RS-485) and communication parameters of ABB SC510 3BSE003832R1 to match connected devices.
  3. Follow DIN rail mounting guidelines for ABB SC510 3BSE003832R1 to ensure stable backplane bus connection.
  4. Keep wiring within the 1200m limit (RS-485) for ABB SC510 3BSE003832R1 to avoid signal attenuation.
  5. Regularly check wiring connections of ABB SC510 3BSE003832R1 in vibrating environments to maintain communication integrity.
