ABB RK682011-BA

Description

Product Description

The ABB RK682011-BA is a highly reliable and robust industrial power supply module, forming a critical part of the electrical infrastructure within automation control cabinets. This specific model, the ABB RK682011-BA, is designed to convert standard AC mains voltage into a stable and regulated 24V DC output, which is the universal power standard for PLCs, relays, sensors, actuators, and other control system components. For detailed specifications and sourcing information, the ABB RK682011-BA ensures the availability of clean and uninterrupted power, which is foundational to the stability and reliability of the entire automation system. Its rugged design and consistent performance make it a preferred choice for system integrators and maintenance engineers.

Product Parameters

• Product Type: Single-Phase Switch-Mode Power Supply (SMPS).
• Brand & Series: ABB, part of the CP-E range or similar industrial power supply series.
• Model: ABB RK682011-BA.
• Input Voltage: Typically accepts a wide-range AC input (e.g., 100-240V AC, 50/60 Hz).
• Output Voltage: Regulated 24V DC.
• Output Current: Rated for a specific amperage, commonly 10A (e.g., 240W output power).
• Efficiency: High efficiency rating (e.g., >90%) to minimize heat generation and energy loss.
• Protection Features: Includes short-circuit, overload, and overvoltage protection. May also feature overtemperature protection.
• Cooling: Convection-cooled (fanless) design for silent operation and high reliability, or with an integrated fan for higher power models.
• Status Indicators: LED indicators for input power (AC OK) and output power (DC OK).
• Connection: Screw-type terminals for both input and output connections.
• Mounting: Designed for standard DIN-rail mounting (TS35/7.5 or TS35/15).
• Safety & EMC: Complies with relevant international standards for industrial equipment (UL, CE, cULus) and has good electromagnetic compatibility (EMC).

Advantages and Features

The ABB RK682011-BA offers significant advantages in terms of reliability and ease of use. Its key feature is the wide input voltage range, which provides immunity against line voltage fluctuations common in industrial settings. The power supply provides a stable and low-ripple DC output, which is crucial for the precise operation of sensitive electronic controls and analog sensors. Its robust, fanless design (where applicable) eliminates a common point of failure, ensuring silent operation and suitability for dusty environments. Comprehensive protection circuits safeguard both the power supply itself and the connected load from damage due to faults. The compact form factor and DIN-rail mounting make the ABB RK682011-BA easy to install and integrate into any control panel.

Application Cases in Application Fields

This power supply is a universal component found in virtually every industry utilizing automation. In automotive manufacturing, the ABB RK682011-BA powers the PLCs, safety controllers, and sensor networks across robotic welding and assembly lines. In food and beverage processing, it provides clean power to control systems for mixers, fillers, and packaging machines. Within water treatment facilities, it energizes the I/O racks and instruments of the SCADA system controlling pumps and chemical dosing. For material handling in warehouses, it supplies power to the PLCs governing sortation conveyors and automated storage/retrieval systems (AS/RS). Its reliability makes it a backbone component in any control cabinet.

Comparisons with Competing Products

Compared to generic or economy-grade power supplies, the ABB RK682011-BA offers superior build quality, better output regulation, and higher reliability, which translates to less downtime and longer service life. It often features better surge protection and noise immunity. Against other premium industrial brands like Siemens (SITOP) or Phoenix Contact (QUINT), the ABB RK682011-BA provides comparable performance and features. The choice may then come down to brand preference within an existing facility, global service support, or specific form-factor and connection preferences. The ABB RK682011-BA is known for its robustness and is a trusted component in ABB’s own system solutions.

Selection Suggestions and Precautions

• Load Calculation: Accurately calculate the total 24V DC current consumption of all devices in the cabinet (PLCs, I/O modules, relays, sensors, HMIs). Select the ABB RK682011-BA (or a model with appropriate current rating) with a minimum of 20-30% headroom for future expansion and optimal efficiency.
• Input Power Quality: Ensure the available AC mains supply is within the specified input range of the power supply. In areas with very poor power quality, consider adding an upstream line conditioner or surge protector.
• Derating: Account for ambient temperature. If installed in a hot enclosure, the power supply may need to be derated (i.e., provide less than its maximum output current). Consult the derating curve in the datasheet.
• Parallel Operation: If redundancy or higher capacity is needed, check if the ABB RK682011-BA supports parallel operation with load sharing and decoupling diodes.
• Wiring and Fusing: Follow proper electrical practices. Use appropriately sized wires and install a correctly rated fuse or circuit breaker on the AC input side for protection.
