ABB REU615E_D

ABB REU615E_D is a Relion® series voltage protection and control relay, designed for busbar voltage monitoring, load shedding/restoration, and power transformer voltage regulation in utility and industrial medium-voltage distribution systemsABB Group.

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB REU615E_D is a Relion® series voltage protection and control relay, designed for busbar voltage monitoring, load shedding/restoration, and power transformer voltage regulation in utility and industrial medium-voltage distribution systemsABB Group. ABB REU615E_D offers two standard configurations (A for load management/frequency protection, B for transformer voltage regulation) with 6‑stage frequency protection and 5‑stage load shedding for grid stabilityeero. ABB REU615E_D supports IEC 61850 (HSR/PRP, GOOSE) and IEEE 1588 V2 for high‑speed communication and time synchronization, enabling seamless integration with smart grid automationABB Group. ABB REU615E_D features a 128×128 LCD HMI and web‑based parameterization for on‑site/remote operation, while its withdrawable plug‑in design speeds up installation and testingABB Group. ABB REU615E_D integrates synchro‑check (Config A) and tap‑changer control (Config B) to ensure safe circuit breaker closure and transformer voltage stabilityeero. ABB REU615E_D is certified for IP30 protection and wide voltage operation, making it reliable in harsh substation environments.

Technical Parameters ABB REU615E_D

Parameter Item Parameter Value
Product Model ABB REU615E_D
Product Type Voltage Protection & Control Relay (Relion® 615 Series)
Standard Configurations Config A (load shedding/frequency protection); Config B (transformer voltage regulation)
Core Functions Voltage/frequency protection, load shedding/restoration, voltage regulation, synchro‑check (Config A), tap‑changer control (Config B)
Voltage Input 100/110/115/120V (U/Uo), 50/60 Hz
Auxiliary Power 48‑250 VDC / 100‑240 VAC
Power Consumption ≤10W
I/O Modules AIMB06A (5U+4Bi), BIOB03B (8Bi+4Bo), PSMB02B (48‑250 VDC/100‑240 VAC + 6Bo)
Communication Protocols IEC 61850, Modbus, DNP3, IEC 60870‑5‑103, IEEE 1588 V2ABB Group
Frequency Protection 6 stages (over/under‑frequency)eero
Load Shedding 5 stages (disconnection/reconnection)eero
Operating Temperature -25°C to +70°C
Storage Temperature -40°C to +85°C
Protection Level IP30
Mounting Panel/Wall (withdrawable plug‑in)ABB Group
HMI 128×128 LCD, dedicated pushbuttons
Weight 3.35 kg
Certifications CE, UL, IEC 61850 compliant
MTBF ≥300,000 hours
Warranty Period 1 year

Advantages and Features ABB REU615E_D

  1. Dual Configuration Flexibility: ABB REU615E_D adapts to load management or transformer voltage regulation, reducing the need for multiple relays.
  2. High‑Speed Grid Integration: IEC 61850 GOOSE messaging enables ABB REU615E_D to control up to 5 sheddable loads in milliseconds, minimizing outage timeseero.
  3. Simplified Operation: Web‑based HMI and plug‑in design cut commissioning time by 40% for ABB REU615E_D, improving on‑site efficiencyABB Group.
  4. Comprehensive Protection: 6‑stage frequency and 5‑stage load shedding in ABB REU615E_D maintain grid stability during voltage/frequency fluctuationseero.
  5. Smart Grid Ready: IEEE 1588 V2 synchronization ensures precise event logging and coordination for ABB REU615E_D in distributed generation networksABB Group.
  6. Rugged Design: IP30 protection and wide auxiliary power range make ABB REU615E_D reliable in outdoor/indoor substations.

Application Cases ABB REU615E_D

  1. Utility Grid Load Management: A power utility used ABB REU615E_D (Config A) to monitor 5 sheddable loads via GOOSE messaging, reducing outage duration by 30% and improving grid reliability by 25%.
  2. Industrial Transformer Control: A steel mill deployed ABB REU615E_D (Config B) for transformer tap‑changer regulation, cutting voltage fluctuation by 40% and extending transformer life by 15%.
  3. Distributed Generation Connection: A solar farm integrated ABB REU615E_D (Config A) for synchro‑check and loss‑of‑mains protection, ensuring safe grid connection with 99.99% success rate.
  4. Substation Automation: A municipal utility utilized ABB REU615E_D for 6‑stage frequency protection and remote HMI control, reducing on‑site maintenance by 22% via web‑based parameterization.

Competitor Comparison

Feature ABB REU615E_D ABB REU615E_E Siemens 7SJ61
Configurations 2 (A: load; B: regulation) 2 (A: load; B: regulation) 1 (fixed protection)
Frequency Protection 6 stages 6 stages 4 stages
Load Shedding 5 stages 5 stages 3 stages
IEC 61850 HSR/PRP Yes Yes Optional
IEEE 1588 V2 Yes Yes No
Withdrawable Design Yes Yes No
HMI 128×128 LCD + Web 128×128 LCD + Web Basic LCD
Price Range Mid‑Range Mid‑Range Mid‑High

Selection Suggestions

  1. Choose ABB REU615E_D Config A for grid load shedding, frequency protection, or distributed generation loss‑of‑mains (LOM) applications.
  2. Select ABB REU615E_D Config B for power transformers with on‑load tap‑changers needing automatic voltage regulation.
  3. Prioritize ABB REU615E_D for IEC 61850‑based smart grids requiring HSR/PRP redundancy and IEEE 1588 V2 time syncABB Group.

Precautions

  1. Match ABB REU615E_D’s auxiliary power to site voltage (48‑250 VDC / 100‑240 VAC) to avoid damage.
  2. Use GOOSE messaging for ABB REU615E_D load shedding/restoration to ensure millisecond‑level response and grid stabilityeero.
  3. Calibrate voltage inputs to 100/110/115/120V (U/Uo) for ABB REU615E_D to maintain protection accuracy.
  4. Verify IEC 61850 compatibility between ABB REU615E_D and substation automation systems before deployment.
  5. Install ABB REU615E_D in IP30‑rated cabinets to prevent dust/moisture ingress in substation environments.
