ABB PP836 3BSE042237R1

Description

Product Description

The ABB PP836 3BSE042237R1 is a high-performance, redundant power supply module designed for the ABB AC 800M high integrity controller family, which is a core component of the System 800xA distributed control system (DCS). This module is engineered to deliver stable, clean, and reliable DC power to the controller’s CPU, communication modules, and associated I/O racks. The PP836 3BSE042237R1 is specifically built for critical process automation applications where maximum system availability is required. Its design supports hot-swap and N+1 redundancy configurations, ensuring uninterrupted operation even in the event of a single power supply failure. Implementing the ABB PP836 3BSE042237R1 provides a robust power foundation for mission-critical control systems.

Technical Parameters

• Device Type: Redundant Power Supply Module (for AC 800M Controller).
• Manufacturer: ABB.
• Compatible System: ABB AC 800M Controller (e.g., PM851, PM861, PM891) within System 800xA.
• Input Voltage: 24 V DC (nominal), with a wide operating range (e.g., 19.2 – 30 V DC).
• Output Power: 60 Watts continuous output.
• Output Voltages: Provides the required system voltages to the controller backplane (typically +5V, +3.3V, and possibly +/-12V).
• Redundancy: Supports parallel operation for N+1 redundancy. Modules share the load, and if one fails, the other seamlessly takes the full load without interruption.
• Hot-Swappable: Can be inserted or removed from a powered controller baseplate without shutting down the control system, facilitating maintenance without process interruption.
• Protections: Includes protection against overvoltage, undervoltage, overload, and short-circuit conditions.
• Status Indication: Comprehensive LED indicators for input power (24V OK), output power (PWR OK), module status (RUN), and fault conditions (ERR).
• Mounting: Plugs directly into designated slots on the AC 800M controller’s power supply base unit.

Advantages and Features

• High Availability through Redundancy: The core advantage of the PP836 3BSE042237R1 is its built-in support for redundant configuration, eliminating the power supply as a single point of failure and maximizing control system uptime.
• Hot-Swap Capability: Allows for the replacement of a faulty power module during ongoing plant operation, which is essential for meeting the high availability requirements of continuous processes.
• Superior Power Quality and Stability: Provides exceptionally clean and regulated power to the sensitive electronics of the AC 800M controller, ensuring stable processor operation and reliable communication.
• Integrated Diagnostics and Monitoring: The status LEDs and system-integrated diagnostics provide immediate visual and software-based feedback on the health of the ABB PP836 3BSE042237R1, enabling predictive maintenance.
• Optimized for System 800xA Integration: As a genuine ABB component, it is fully recognized, configured, and monitored within the System 800xA engineering and operator workplace environment.

Application Cases in Various Fields

• Oil & Gas (Refineries, LNG): Powering safety and process control systems (ESD, PCS) where uninterrupted operation is critical for safety and production.
• Chemical & Petrochemical Plants: Providing reliable power to batch and continuous process control systems managing reactors, distillation columns, and utilities.
• Power Generation: Ensuring continuous power for turbine control, balance-of-plant, and DCS systems in thermal, hydro, and nuclear power stations.
• Pharmaceutical & Biotechnology: Supporting control systems in validated processes where system failure can lead to massive product loss.
• Pulp & Paper: Powering the DCS controlling digesters, paper machines, and recovery boilers.

Comparison with Competing Products

The ABB PP836 3BSE042237R1 competes with redundant power supplies for other high-end process controllers, such as Siemens (S7-400H PS 407), Emerson (DeltaV PK Controller), and Honeywell (C300 PM). Its key competitive strengths are:

• Native Ecosystem Performance: It is not a generic supply but a component optimized for the electrical characteristics and firmware of the AC 800M controller, ensuring guaranteed performance and compatibility.
• Seamless Redundancy Management: The redundancy and load-sharing logic are handled intelligently between the modules and the controller firmware, offering a more integrated solution than externally managed redundant supplies.
• System 800xA Diagnostics: Its status is fully integrated into the plant-wide diagnostic and alarm system of System 800xA, providing operators with a unified view of controller health.

Selection Suggestions and Precautions

1. Verify Controller Compatibility: Confirm that the PP836 3BSE042237R1 is compatible with your specific AC 800M CPU model (PM85x/86x/89x) and the corresponding power supply base unit.
2. Always Use in Redundant Pairs for Critical Loops: For any application where controller downtime is unacceptable, always install two ABB PP836 3BSE042237R1 modules in a redundant configuration from the start. Do not use a single module for critical control.
3. Ensure High-Quality Primary 24V DC Source: The reliability of the redundant system depends on a clean and stable primary 24V DC source. Use a high-quality, redundant AC-to-DC power supply system with appropriate buffering (e.g., batteries or capacitors) to protect against mains failure.
4. Follow Hot-Swap Procedures Precisely: When replacing a module, strictly follow the ABB hot-swap procedure outlined in the manual. Insert and remove modules smoothly and ensure the controller is in the correct operational state.
5. Monitor System Diagnostics: Regularly check the power supply status via the System 800xA operator station or the module’s LEDs. Investigate any fault indications immediately, even if the system is running on the redundant partner.
