ABB NTAC-02 58967441E | Encoder Interface Board, OEM Stock

Description

Product Introduction

The ABB NTAC-02 is a pulse encoder interface module designed for the ACS800 series variable frequency drives. This module provides high-resolution speed and position feedback for closed-loop vector control applications, enabling precise speed regulation, torque control, and positioning. The NTAC-02 mounts directly into the drive control unit (RMIO or RDCU slot) and accepts input from incremental encoders with TTL (5 V) or HTL (24 V) output signals.

The ACS800 drive platform is one of ABB’s most widely installed AC drive families, with hundreds of thousands of units in operation across industries including material handling, cranes, hoists, winders, and precision conveyors. The NTAC-02 was the standard encoder interface for closed-loop control applications on ACS800 drives. As ABB has transitioned to the ACS880 platform, the ACS800 product line and its associated option boards have been discontinued. For facilities still operating ACS800 drives with closed-loop control, sourcing verified NTAC-02 modules is essential for maintaining precision motion control.

Key Technical Specifications

Key Selling Points & Differentiators

• ACS800 Closed-Loop Control: Enables vector control with encoder feedback for precise speed regulation, torque control, and positioning applications.
• Dual Voltage Encoder Support: Selectable 5 V DC (TTL) or 24 V DC (HTL) encoder supply voltage, compatible with a wide range of incremental encoders.
• High-Speed Input: Up to 500 kHz input frequency supports high-resolution encoders and high-speed motor applications.
• Plug-in Installation: Mounts directly into the drive control unit with no additional wiring or mounting hardware. Field wiring connects to removable terminal blocks on the module.
• Authenticity Guarantee: Each unit undergoes visual inspection for ABB OEM markings, serial number traceability, and PCB integrity. We test every module on a live ACS800 drive before shipping.

Frequently Asked Questions (FAQ)

Q: Which ABB drives is the NTAC-02 compatible with?
The NTAC-02 is designed for the ABB ACS800 series drives. It is not compatible with ACS550, ACS880, or other ABB drive families without an adapter or interface board. It mounts in the RMIO (I/O extension) slot or RDCU slot on the drive control unit.

Q: Is this module discontinued?
Yes. ABB has phased out the ACS800 drive platform in favor of the ACS880 series. The NTAC-02 is no longer in active production. Availability is limited to new surplus and tested used inventory. For ACS800 drives still in operation, we recommend securing spares while stock remains available.

Q: What types of encoders are compatible with the NTAC-02?
The NTAC-02 supports incremental encoders with:

• TTL (5 V) differential or single-ended outputs (RS-422)
• HTL (24 V) differential or single-ended outputs
• A, B, Z channels (quadrature with index pulse)

It does not support absolute encoders (SSI, EnDat, BiSS, etc.) or resolvers. For absolute encoder feedback, a different option board such as the NTAC-01 or RTAC-01 is required.

Q: How do I configure the NTAC-02 for my application?
Configuration is done through the drive parameters. Key parameters include:

• Parameter 50.01: Encoder type selection
• Parameter 50.02: Encoder supply voltage (5 V or 24 V)
• Parameter 50.03: Pulses per revolution (PPR)
• Parameter 50.04: Encoder direction (normal/reverse)

If you are replacing a failed NTAC-02, the drive parameters remain unchanged. The new module will operate with the existing parameter settings.

Q: Can I install the NTAC-02 while the drive is powered?
No. The drive must be powered down and locked out before installing or removing any option board. The control unit backplane is not hot-swappable. Attempting to install or remove a board with power applied can damage the board, the drive control unit, or both.

Q: What are the maximum cable lengths for encoder wiring?
Maximum cable lengths depend on encoder type and cable quality:

• TTL (5 V): Up to 50 meters (164 feet) with shielded twisted-pair cable
• HTL (24 V): Up to 100 meters (328 feet) with shielded twisted-pair cable

For longer runs, consider using a line driver or signal conditioner. Always use shielded cable and ground the shield at the drive end only.

Q: What testing do you perform before shipping?
We test every NTAC-02 on a live ACS800 drive with a simulated encoder signal. Our test procedure includes:

• Visual inspection for physical damage, corrosion, or previous repairs
• Edge connector cleaning and inspection
• Drive communication verification (board recognized by drive)
• Encoder power supply verification (5 V and 24 V)
• A, B, Z channel input testing with frequency sweep
• Speed feedback accuracy verification
• 24-hour continuous power-on soak test

A test report with test results is included with each shipment.
