ABB DI880 3BSE028586R1

Technical Specifications

Category Details
Module Type Digital Input (DI) Module
Channel Count 16 independent 24V DC input channels
Input Voltage Range 19.2–30V DC (sourcing/sinking configurable)
Input Current 6–10 mA per channel (active state); <0.1 mA (inactive state)
Safety Compliance SIL 2 (IEC 61508); supports “1oo2” voting logic
Noise & Surge Protection EMI/RFI compliance: IEC 61000-6-2; Surge protection: 2 kV (transient)
Operating Temperature -40°C to +70°C (-40°F to +158°F)
Power Requirements 24V DC (±10%); Power consumption: ≤6W
Communication ABB AC 800M backplane; compatible with System 800xA DCS
Certifications ATEX (Zone 2), IECEx (Zone 2), UL, CE, CCC
Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB DI880 3BSE028586R1 is a high-reliability digital input (DI) module from ABB, designed exclusively for integration with ABB’s AC 800M controller and System 800xA DCS. It specializes in collecting discrete status signals from industrial sensors (e.g., limit switches, pressure switches, proximity sensors) across sectors like oil & gas, chemical processing, and power generation, serving as a critical link between field devices and centralized control systems for real-time equipment monitoring.

Product Description

ABB DI880 3BSE028586R1 belongs to ABB’s family of Advant Controller I/O modules, a line recognized for seamless compatibility with ABB’s automation ecosystem and adherence to strict industrial safety standards. This module features 16 independent digital input channels, each supporting 24V DC signals (sourcing or sinking configurable)—the industry standard for most discrete sensors. A defining trait of ABB DI880 3BSE028586R1 is its advanced noise immunity: each channel includes built-in EMI/RFI filtering (compliant with IEC 61000-6-2) and transient surge protection (up to 2 kV), ensuring stable signal collection even in high-interference environments (e.g., near large motors or high-voltage cables in refineries).
Another key advantage of ABB DI880 3BSE028586R1 is its support for safety-critical applications. It meets SIL 2 requirements (per IEC 61508) and offers configurable “1oo2” (1-out-of-2) voting logic for critical inputs—two channels can monitor the same sensor signal, and the module validates data consistency before transmitting to the DCS. This prevents false alarms caused by sensor faults, a critical feature for systems like emergency shutdown (ESD) valves in gas processing plants. For example, ABB DI880 3BSE028586R1 can monitor the “valve fully closed” status of an ESD valve: if both paired channels confirm the valve is open when it should be closed, the module triggers an immediate alert to the System 800xA DCS.
ABB DI880 3BSE028586R1 also excels in diagnostics and flexibility. It provides real-time channel health monitoring, detecting issues like open circuits, short circuits, and overvoltage, with fault codes transmitted directly to the AC 800M controller. Using ABB’s Control Builder M software, users can adjust input delay filters (0.1–100 ms) to ignore vibration-induced false signals (e.g., from sensors on rotating equipment like pumps). Additionally, the module supports hot-swapping—faulty units can be replaced without shutting down the I/O rack, minimizing downtime for 24/7 operations like chemical batch processing.
In terms of durability, ABB DI880 3BSE028586R1 features a compact DIN rail-mounted design with a wide operating temperature range (-40°C to +70°C) and an IP20 rating (suitable for control cabinet installation). It is certified to ATEX and IECEx standards for Zone 2 hazardous areas, allowing use in oil rigs or chemical storage facilities without additional explosion-proof enclosures.

Technical Specifications

Category Details
Module Type Digital Input (DI) Module
Channel Count 16 independent 24V DC input channels
Input Voltage Range 19.2–30V DC (sourcing/sinking configurable)
Input Current 6–10 mA per channel (active state); <0.1 mA (inactive state)
Safety Compliance SIL 2 (IEC 61508); supports “1oo2” voting logic
Noise & Surge Protection EMI/RFI compliance: IEC 61000-6-2; Surge protection: 2 kV (transient)
Operating Temperature -40°C to +70°C (-40°F to +158°F)
Power Requirements 24V DC (±10%); Power consumption: ≤6W
Communication ABB AC 800M backplane; compatible with System 800xA DCS
Certifications ATEX (Zone 2), IECEx (Zone 2), UL, CE, CCC

Advantages and Features

  1. SIL 2 Safety & Voting Logic: ABB DI880 3BSE028586R1 is ideal for safety-critical loops (e.g., ESD systems), with “1oo2” voting reducing false alarms and improving reliability.
  2. Strong Noise Immunity: Built-in filtering and surge protection ensure stable signal collection in high-interference industrial environments.
  3. Seamless ABB Integration: Native compatibility with AC 800M controllers and System 800xA DCS eliminates third-party adapter needs.
  4. Hot-Swapping & Diagnostics: Minimizes downtime via hot-swapping and enables proactive maintenance with real-time fault monitoring.
  5. Hazardous Area Ready: ATEX/IECEx certifications allow direct use in Zone 2 environments, simplifying installation.

Application Cases by Industry

  • Oil & Gas (ESD Valve Monitoring): In an offshore gas platform, ABB DI880 3BSE028586R1 monitors 8 ESD valve position sensors. Using “1oo2” voting, two channels per valve confirm status—if a valve fails to close during an emergency, the module alerts the System 800xA DCS, triggering a platform-wide shutdown.
  • Chemical Processing (Reactor Door Safety): In a batch chemical reactor, ABB DI880 3BSE028586R1 tracks 4 door seal sensors. If any sensor detects an open seal (DI signal), the module stops raw material feed pumps via the DCS, preventing chemical leaks and ensuring operator safety.
  • Power Generation (Turbine Auxiliary Monitoring): In a coal-fired power plant, ABB DI880 3BSE028586R1 collects status signals from 12 turbine auxiliary pumps (e.g., lubrication, cooling). A “pump offline” signal triggers an alarm, prompting maintenance before turbine damage occurs.

Comparison with Competitors

Feature ABB DI880 3BSE028586R1 Competitor 1 (Siemens SM 321) Competitor 2 (Emerson DeltaV DI Module)
Safety Rating SIL 2 (1oo2 voting) SIL 1 SIL 2 (no voting)
Noise Protection IEC 61000-6-2 (high) IEC 61000-6-3 (basic) IEC 61000-6-2 (high)
DCS Compatibility ABB System 800xA Siemens SIMATIC Emerson DeltaV
Hot-Swapping Supported Not supported Supported
Operating Temp Range -40°C to +70°C 0°C to +60°C -40°C to +70°C

Selection Recommendations and Precautions

Selection Recommendations

  1. ABB Ecosystem Users: Prioritize ABB DI880 3BSE028586R1 if using AC 800M controllers or System 800xA DCS for plug-and-play integration.
  2. Safety-Critical Loops: Choose this module for SIL 2 applications (e.g., ESD, reactor safety) to leverage its “1oo2” voting logic.
  3. High-Interference Sites: Use ABB DI880 3BSE028586R1 in refineries or power plants to avoid false signals from EMI/RFI.

Precautions

  1. Voltage Matching: Ensure sensors use 19.2–30V DC—lower voltages (e.g., 12V DC) will cause unreliable signal detection.
  2. Wiring Best Practices: Use shielded twisted-pair cables, grounded at one end, to maximize noise immunity.
  3. Voting Logic Setup: When configuring “1oo2” voting, use identical sensors for paired channels to ensure consistent signal validation.
  4. Regular Calibration: Test channel responsiveness annually with a signal simulator to maintain SIL 2 compliance.

DI880
