ABB CP800

Description

Product Description

The ABB CP800 is a highly versatile and scalable Automation Panel PC series designed to serve as the central operator interface and computing platform within industrial control systems. More than just a standard PC, this hardened panel-mounted computer integrates a high-brightness TFT display, touch screen, and a robust industrial-grade computing core into a single, compact unit designed for 24/7 operation in demanding environments. The ABB CP800 functions as a critical human-machine interface (HMI), data visualization station, and in many configurations, a full-fledged controller or gateway, running ABB’s System 800xA or other automation software. Its deployment allows operators to monitor process graphics, acknowledge alarms, adjust setpoints, and execute commands directly from the plant floor. The modular design of the ABB CP800 series offers flexibility in performance, screen size, and I/O connectivity, making it a cornerstone for modern, integrated control room and field panel solutions. Selecting the appropriate ABB CP800 model is fundamental to creating an effective and reliable operator interaction layer.

Product Parameters

• Product Type: Industrial Automation Panel PC / HMI.
• Display: Various sizes available (commonly from 12.1″ to 24″), typically with LED backlighting, high brightness for visibility, and analog resistive or projected capacitive touch screens.
• Processor: Based on industrial-grade Intel Core i3, i5, or i7 processors, providing scalable computing power.
• Memory & Storage: Equipped with DDR3/DDR4 RAM and solid-state drives (SSD) for reliability and shock resistance.
• Operating System: Typically supports Microsoft Windows 10/11 IoT Enterprise or Linux, certified for use with ABB automation suites.
• Communication Ports: Comprehensive set including multiple Ethernet ports (some with Gigabit and PROFINET), USB, serial (RS-232/485), and optional fieldbus cards (PROFIBUS, DeviceNet, etc.).
• Protection Rating: High ingress protection rating (typically IP65 for the front panel) for dust and water resistance, suitable for wash-down or harsh environments.
• Mounting: Designed for panel mounting (flush or surface) in control cabinets or operator consoles.
• Certifications: Compliant with key industrial standards for EMC, shock, vibration, and safety.

Advantages and Features

• Robust Industrial Design: Built to withstand extremes of temperature, humidity, vibration, and electrical noise commonly found in factories and process plants, ensuring maximum uptime.
• Unified Automation Experience: When paired with ABB’s 800xA system, the ABB CP800 delivers a seamless, role-based operator environment with integrated faceplates, alarm management, and historian access from a single station.
• Scalable Performance: The series offers a range of models from basic HMI stations to powerful controller nodes, allowing users to match computing power to the application’s complexity, from simple monitoring to advanced process optimization.
• Multi-Function Capability: Can be configured as an Operator Station, Engineering Station, Application Server, or even a Control Builder node, consolidating functions and reducing hardware footprint.
• Excellent Connectivity: The wide array of built-in and expandable communication ports enables easy integration with PLCs, drives, third-party devices, and enterprise networks.

Application Cases in Application Fields

• Water Treatment Control Room: Serving as the main operator station in a central control room, displaying a mimic diagram of the entire plant, trending historical data, and managing alarms for pumps, valves, and chemical dosing.
• Pharmaceutical Batch Process: Mounted on a skid-mounted bioreactor, providing operators with step-by-step batch recipes, real-time parameter displays (temperature, pH), and electronic batch record review.
• Automotive Manufacturing Line: Installed at a cell controller station, displaying production counts, machine status, and fault diagnostics for a robotic welding line, allowing for quick operator intervention.
• Oil & Gas Offshore Platform: Functioning as a ruggedized local operator panel in a hazardous area enclosure, providing control and monitoring for a gas compression module.

Comparisons with Competing Products

Competing products include industrial panel PCs from manufacturers like Siemens (Simatic IPC), Rockwell Automation (PanelView Plus), and Beckhoff (CPx series). The ABB CP800 distinguishes itself through its deep, native integration with the ABB System 800xA, offering a level of operational and engineering synergy that generic panels cannot achieve. Compared to standard HMIs, it offers significantly greater computing power and flexibility, allowing it to run full SCADA or DCS client software. Versus a standard commercial PC in an industrial enclosure, the ABB CP800 is a pre-engineered, tested, and supported solution with guaranteed compatibility and longer lifecycle support. Its key advantage is being the recommended and optimized hardware platform for ABB’s high-end control systems, ensuring performance, reliability, and single-vendor support.

Selection Suggestions and Precautions

1. Application Role Definition: Clearly define whether the ABB CP800 will be used as a pure operator station, a combined operator/engineering station, or a server. This dictates the required processor, memory, and software licensing.
2. Environmental Assessment: Verify the ambient temperature, potential for wash-down, and hazardous area classification (if applicable) to select the correct model with the appropriate IP rating and certifications.
3. Software and Licensing: Account for the cost and compatibility of the required operating system and automation software (e.g., 800xA, CP600 HMI software). The hardware is only one part of the total system cost.
4. Integration Planning: Plan the communication interfaces needed to connect to controllers, networks, and peripherals. Order optional communication cards (e.g., for PROFIBUS) at the time of purchase if required.
