ABB COM0034 2RCA023019A0004C: Communication Interface Module for AC 31/AC 110

Product Description

The ABB COM0034 2RCA023019A0004C is a communication interface module designed for the ABB Advant Controller 31 (AC 31) and Advant Controller 110 (AC 110) families within the Advant and MOD 30M distributed control system (DCS) range. This module serves as a critical gateway, providing a serial communication port—commonly for protocols like RS-232 or RS-485—to enable data exchange between the PLC controller and external devices. The ABB COM0034 2RCA023019A0004C facilitates connections to peripheral equipment such as operator terminals (OTs), programming devices, printers, or other supervisory systems for functions like program upload/download, data logging, and operator interfacing. Its reliable performance was essential for the configuration and external communication of these established automation platforms.

Product Parameters

• Product Type: Serial Communication Interface Module
• Manufacturer: ABB
• Part Number: COM0034 2RCA023019A0004C
• Compatible Controller: Advant Controller 31 (AC 31), Advant Controller 110 (AC 110)
• Communication Interface: Typically provides one or more serial ports (RS-232-C/V.24 and/or RS-422/485).
• Protocol Support: Often used for point-to-point communication, supporting proprietary or standard protocols for programming and data transfer.
• Data Transfer Rate: Configurable baud rates (e.g., up to 19.2 kbps or higher).
• Power Supply: Powered via the controller’s backplane.
• Mounting: Installs in a dedicated communication module slot on the AC 31 or AC 110 rack.

Advantages and Features

The primary advantage of the ABB COM0034 2RCA023019A0004C was its provision of a standardized, reliable serial communication path for the otherwise self-contained AC 31/110 controllers. It enabled essential engineering and operational functions, such as connecting a programming terminal for logic development and troubleshooting. The module was designed for robust industrial use, with electrical isolation and noise immunity to ensure stable communication in plant environments. Its integration was straightforward within the controller’s architecture, and configuration parameters (like baud rate and parity) were typically set via DIP switches or software. The ABB COM0034 2RCA023019A0004C was a key enabler for integrating these controllers into wider automation systems.

Application Cases in Various Fields

This module was used in any AC 31 or AC 110 application requiring external connectivity. In Pulp and Paper Mills, the ABB COM0034 2RCA023019A0004C connected a controller to a local programming terminal for maintenance or to a serial printer for production reports. Within Chemical Batch Processes, it might have been used to download new recipe parameters from a supervisory computer. For Machine Control, it provided the port for initial programming and occasional monitoring. It was also fundamental for system commissioning and servicing across all industries where these controllers were deployed.

Comparisons with Competing Products

During its era, competing PLCs from Siemens (Simatic S5) or Allen-Bradley (PLC-5) offered similar serial communication modules (e.g., CP 525, 1785-KA). The ABB COM0034 2RCA023019A0004C was distinguished by its specific compatibility with the ABB Advant controller family and its associated software tools (like ABB MasterTool). Compared to modern Ethernet-based communication, this serial module is technologically obsolete but remains critical for maintaining and interfacing with the vast installed base of these reliable legacy controllers. Its value today lies in its role as a spare part for lifecycle support, not in advanced features.

Selection Suggestions and Precautions

1. Controller and Rack Compatibility: Confirm your controller is an AC 31 or AC 110 and that you have an available communication module slot. The ABB COM0034 2RCA023019A0004C is not compatible with newer ABB platforms like AC 800M.
2. Protocol and Cable Compatibility: Identify the specific communication protocol and pinout required by the device you are connecting to (e.g., programming PC, HMI). You will likely need a special serial cable (often a null-modem cable) and may need to configure DIP switches on the ABB COM0034 2RCA023019A0004C for baud rate and data format.
3. Software and Drivers: Connection to a modern PC may require legacy software (e.g., ABB MasterTool) and potentially a USB-to-serial adapter with appropriate drivers. Communication settings in the software must match the hardware settings on the module.
4. Spare Part Sourcing: As a legacy part, source the ABB COM0034 2RCA023019A0004C from reputable industrial automation surplus specialists who can verify functionality. Be cautious of old stock with degraded components.
5. Installation During Downtime: Replacing or installing this module typically requires powering down the controller rack. Plan for a maintenance window and follow safe shutdown procedures. Ensure any communication configuration (DIP switches) is documented and replicated if replacing a unit.
