ABB 5SHX1060H0003

Description

Product Overview and Description

The ABB 5SHX1060H0003 is a high-power, high-voltage insulated-gate bipolar transistor (IGBT) module, a critical semiconductor component used within ABB’s ACS1000 family of medium-voltage variable frequency drives (VFDs). This module does not function as a traditional PLC part but is a fundamental power electronic component within the drive’s inverter section, which is itself a critical piece of industrial automation for controlling large motors. The primary function of the ABB 5SHX1060H0003 is to act as a high-speed, solid-state switch, rapidly modulating DC bus voltage to synthesize a variable frequency and voltage AC waveform to precisely control the speed and torque of medium-voltage induction or synchronous motors.  The performance and reliability of the entire drive hinge on these power modules. When specifying or maintaining an ACS1000 drive, understanding the role and requirements of the ABB 5SHX1060H0003 is essential for system reliability.

Detailed Product Parameters

• Function: High-Power Dual IGBT Module (typically a half-bridge or chopper configuration) for medium-voltage inverters.
• Voltage Rating: Rated for a specific DC link voltage, typically in the range of 1300V, 1700V, or 3300V, suitable for drives operating on 2.3kV, 3.3kV, or 4.16kV AC supplies.
• Current Rating: The “1060” in the part number often denotes a nominal collector current rating, in this case, likely 1060 Amps.
• Module Configuration: Contains two IGBTs and their associated anti-parallel diodes in a single press-pack or module housing, forming a basic switch pair.
• Technology: Utilizes ABB’s proprietary HiPak (High Power Package) or similar press-pack IGBT technology, which is designed for low stray inductance, excellent thermal performance, and high reliability in demanding industrial environments.
• Thermal Characteristics: Has defined thermal impedance and maximum junction temperature (Tj max). Requires precise mounting to a liquid or forced-air cooled heatsink to dissipate substantial switching and conduction losses.
• Gate Driver Interface: Equipped with a standardized gate unit connection for interfacing with the drive’s dedicated gate drive board, which provides the isolated, high-current pulses needed to switch the IGBT.

Key Advantages and Features

1. High Power Density and Reliability: The ABB 5SHX1060H0003 packs high voltage and current handling into a robust, compact package. ABB’s press-pack technology is renowned for its durability and long service life in medium-voltage applications.
2. Low Switching Losses: Advanced IGBT chip technology enables fast switching with controlled di/dt and dv/dt, which improves drive efficiency and allows for higher switching frequencies, leading to better motor current waveforms and reduced motor heating.
3. Excellent Thermal Performance: The direct copper baseplate and press-pack design provide a low thermal resistance path from the silicon die to the heatsink, enabling effective heat dissipation which is critical for maintaining performance and preventing thermal runaway.
4. Integrated Design for Drives: As a core component of the ACS1000 platform, the ABB 5SHX1060H0003 is designed to work seamlessly with ABB’s specific snubber circuits, gate drivers, and protection systems, ensuring safe and stable operation within the drive’s ecosystem.
5. Predictable Failure Mode: Press-pack IGBTs are often designed to fail into a short-circuit state, which allows the drive’s fast-acting fuses or other protection schemes to safely isolate the fault, protecting the rest of the power stack.

Primary Application Fields and Use Cases

This IGBT module is used exclusively within medium-voltage drives controlling large, high-power motors.

• Mining & Minerals: Controlling the speed of grinding mills, conveyors, and large fans for ventilation.
• Oil & Gas: Driving mainline pipeline compressors and pumps in upstream and midstream operations.
• Water & Wastewater: Controlling high-power pumps in large water supply and treatment facilities.
• Power Generation: Acting as starter drives for gas turbine generators or controlling boiler feed pumps.
• Use Case Example: In a mining concentrator plant, an ABB ACS1000 drive using multiple ABB 5SHX1060H0003 IGBT modules controls a 4000kW ball mill motor. The drive varies the motor speed to optimize grinding efficiency based on ore hardness. The robust design of these IGBTs handles the high torque demands and electrical stresses of starting and running the massive mill.

Comparison with Competing Products

• vs. IGBT Modules from Other Vendors (e.g., Infineon, Mitsubishi): While other manufacturers produce similar high-power IGBTs, the ABB 5SHX1060H0003 is specifically designed, tested, and integrated into the ABB ACS1000 drive’s mechanical layout and electrical design. It is not a drop-in replacement for a different brand’s module.
• vs. Older Thyristor/SCR Technology: Compared to older phase-controlled thyristor drives, IGBT-based drives using modules like the 5SHX1060H0003 offer superior power factor, lower harmonic distortion, and much wider speed control range with higher efficiency.
• vs. Lower Voltage IGBTs (e.g., in 480V AC drives): Low-voltage drives use IGBTs with much lower voltage ratings (e.g., 1200V). The ABB 5SHX1060H0003 is part of a medium-voltage class, designed for completely different insulation, snubbing, and cooling requirements.

Selection Suggestions and Important Precautions

• Selection Advice: The ABB 5SHX1060H0003 is not a standalone selection but is specified as part of an ACS1000 drive or as an exact spare part replacement. The selection is 1:1 based on the drive’s manufacturing code and the part number printed on the failed module. Using an incorrect voltage or current rating can lead to immediate catastrophic failure.
• Precaution – High Voltage Hazard: These modules operate at lethal DC voltages (thousands of volts). Strict lockout/tagout (LOTO) procedures, verification of discharged DC link capacitors, and the use of appropriate PPE are mandatory before any physical contact.
• Precaution – Static Sensitivity & Handling: IGBTs are static-sensitive. Handle with ESD precautions. Avoid touching the electrical contacts. The module must also be handled with care to avoid damaging the ceramic substrate or thermal baseplate.
• Precaution – Thermal Interface and Mounting: When replacing, the thermal interface (grease or pad) must be applied correctly, and the mounting torque must be precisely as specified by ABB. Uneven pressure or poor thermal contact will cause localized overheating and premature failure of the new ABB 5SHX1060H0003.
