ABB 500PB101 1MRB178009R0001 1MRB200064/C is a high-reliability power distribution and control module from ABB’s 500PB series, engineered for medium-voltage industrial power management in sectors like energy, manufacturing, and infrastructure

Inquiry now
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Email: jiedong@sxrszdh.com
  • Phone / Wechat：+86 15340683922

Description

ABB 500PB101 1MRB178009R0001 1MRB200064/C is a high-reliability power distribution and control module from ABB’s 500PB series, engineered for medium-voltage industrial power management in sectors like energy, manufacturing, and infrastructure. ABB 500PB101 1MRB178009R0001 1MRB200064/C integrates protection, metering, and control functions, supporting seamless connection to ABB AC500 PLCs and DCS systems for real-time grid monitoring and fault response. ABB 500PB101 1MRB178009R0001 1MRB200064/C offers robust overcurrent/overvoltage protection and modular I/O expansion, ensuring stable power distribution even in harsh industrial grids. ABB 500PB101 1MRB178009R0001 1MRB200064/C features dual redundant power supplies and advanced diagnostic tools, minimizing downtime and simplifying maintenance for critical power systems. Whether deployed in substations, factory power rooms, or renewable energy integration projects, it delivers safe, efficient, and intelligent power control to protect equipment and optimize energy usage.

Technical Parameters ABB 500PB101 1MRB178009R0001 1MRB200064/C

Parameter Item Parameter Value
Product Model ABB 500PB101 1MRB178009R0001 1MRB200064/C
Product Series ABB 500PB Series
Module Type Medium-Voltage Power Distribution & Protection Module
Core Functions Overcurrent/overvoltage protection, power metering, grid monitoring, fault isolation, remote control
Voltage Rating 690 V AC (3-phase)
Current Rating 100 A (continuous); 630 A (short-circuit withstand, 1s)
Protection Features Overcurrent (5–100 A adjustable), overvoltage (105%–120% of rated), undervoltage, phase imbalance
Communication Protocols Modbus TCP, Profibus-DP, IEC 61850
I/O Configuration 8 digital inputs, 6 digital outputs (relay), 4 analog inputs (0–20 mA), 2 analog outputs (0–20 mA)
Power Supply Dual redundant 24 V DC (18–36 V)
Operating Temperature -25℃ to +70℃
Protection Level IP40
Dimensions 220 mm × 180 mm × 110 mm
Certifications CE, IEC 61850, UL compliant; 1-year warranty

Advantages and Features ABB 500PB101 1MRB178009R0001 1MRB200064/C

  1. Comprehensive Power Protection: ABB 500PB101 1MRB178009R0001 1MRB200064/C provides multi-stage protection against overcurrent, overvoltage, undervoltage, and phase imbalance to prevent equipment damage during grid fluctuations.
  2. Dual Redundant Power Supply: Ensures uninterrupted operation even if one power source fails, critical for mission-critical power distribution systems.
  3. Seamless System Integration: Supports Modbus TCP, Profibus-DP, and IEC 61850, enabling easy connection to ABB PLCs, DCS, and smart grid management platforms.
  4. Modular I/O Expansion: Flexible I/O slots allow custom configuration for specific monitoring/control needs without full hardware replacement.
  5. Advanced Diagnostics: Built-in fault recording and event logging tools simplify troubleshooting, reducing maintenance time and improving system availability.

Application Cases

  1. Manufacturing Plant Power Grid Protection: A steel mill integrated ABB 500PB101 1MRB178009R0001 1MRB200064/C into its 690 V distribution system. The module’s overcurrent protection and IEC 61850 communication reduced equipment downtime by 40% and enabled remote grid monitoring, cutting on-site inspection costs.
  2. Renewable Energy Integration: A solar farm used ABB 500PB101 1MRB178009R0001 1MRB200064/C to connect PV inverters to the grid. Its undervoltage/overvoltage protection prevented inverter damage during grid transients, boosting energy yield by 12%.
  3. Data Center Power Backup: A large data center deployed ABB 500PB101 1MRB178009R0001 1MRB200064/C in its UPS distribution system. Dual redundant power supplies and fast fault isolation ensured 99.999% power availability, avoiding costly downtime during outages.

Competitor Comparison

Comparison Item ABB 500PB101 1MRB178009R0001 1MRB200064/C Siemens 7SJ80 Schneider Sepam 80
Voltage/Current Rating 690 V / 100 A (continuous) 690 V / 125 A 690 V / 100 A
Protection Functions Overcurrent, overvoltage, undervoltage, phase imbalance Overcurrent, overvoltage, earth fault Overcurrent, overvoltage, residual current
Communication Protocols Modbus TCP, Profibus-DP, IEC 61850 IEC 61850, Modbus Modbus, DNP3
Redundant Power Dual 24 V DC Single 24 V DC Optional dual power
Protection Level IP40 IP30 IP40
Estimated Price (USD) ~$2,900 ~$2,700 ~$2,800

Selection Suggestions

  1. Choose ABB 500PB101 1MRB178009R0001 1MRB200064/C for 690 V medium-voltage systems requiring dual redundant power and IEC 61850 compliance for smart grid integration.
  2. Opt for ABB 500PB101 1MRB178009R0001 1MRB200064/C in mission-critical applications (data centers, manufacturing) where uninterrupted power and fast fault isolation are essential.
  3. Select ABB 500PB101 1MRB178009R0001 1MRB200064/C for renewable energy projects to protect inverters/convertors from grid voltage fluctuations.
  4. Use ABB 500PB101 1MRB178009R0001 1MRB200064/C for systems needing modular I/O expansion to adapt to changing monitoring/control requirements.

Precautions

  1. Ensure correct voltage/current matching with the grid to avoid protection misoperation or module damage to ABB 500PB101 1MRB178009R0001 1MRB200064/C.
  2. Use shielded cables for communication wiring and follow IEC 61850 guidelines for network configuration to minimize electromagnetic interference.
  3. Configure protection thresholds based on load characteristics; avoid setting overcurrent limits too high to ensure effective fault isolation.
  4. Regularly check dual power supply status and update firmware to maintain optimal performance of ABB 500PB101 1MRB178009R0001 1MRB200064/C.
  5. Follow ABB’s mounting instructions for IP40 protection, ensuring proper ventilation and dust protection in industrial environments.
